Team Bahrain Victorious put the fifth generation Scultura thoroughly through its paces, winning mountain top stages of the Tour de France and the Vuelta a Espana before the bike was even launched.
Gen 5 keeps the Scultura's fabled lightweight, agility and rider comfort focus and even manages to improve on both measures.
The Scultura now incorporates learnings from the Reacto in terms of aerodynamics; they now share the same race proven geometry.
Improving weight, comfort and aerodynamics requires plenty of engineering ingenuity. Round tubes are lighter than aero profiled tubes, fatter tyres are more comfortable but less aerodynamic. There are always compromises to be made.
The new Scultura is the most aerodynamic ever and shows outstanding compliance, providing class-leading rider comfort. The marketing blurb suggests this helps keep the body fresh for the final sprint or ascent. A couple of mountain top, grand tour stage victories underline that point quite well!
Pay in 3 instalments of £1416.67* or in 30 days.
Available on all full price items.
We accept Cycle Scheme
Save up to £1,785
Pay with Cycle Scheme
Damian Harris offers a friendly and professional service. They have good knowledge to make sure your biking requirements are met.
Specification| Availability | In stock |
| BIKE year | 2023 |
| Category | Road Bike |
| Colour | Purple |
| Condition | Brand new |
| bottom bracket | SRAM Pressfit Dub, Presfit 86.5 |
| brake levers | SRAM ED Rival eTAP AXS |
| cassette | SRAM Rival 12s |
| chain | SRAM Rival 12s |
| chainset | SRAM Rival eTAP AXS ; 48-35 tooth chainset; Power Meter. Crank length: 165mm XXS,XS, 170mm S, 172.5mm M, 175mm L,XL |
| fork | Scultura CF3 Disc; Material - carbon; Max. tyre size: 700 x 30c; Disc cooler technology |
| frame | CF3 carbon, race geometry. Internal cable routing, 12mm through axles, flat mount rear brakes with Disc Cooler, 1 1/2inch to 1 1/4inch headtube. Max tyre - 30c |
| front brake | SRAM ED Rival eTAP AXS; hydraulic disc brake caliper with SRAM DB Center lock Paceline; 160mm rotor |
| front derailleur | SRAM Rival eTAP AXS |
| grips | Merida Road Expert |
| handlebar | Merida Expert SL; aluminium; Width: 380mmXXS, 400mm XS-S, 420mm M, 440mm L-XL |
| headset | FSA ACR |
| hub front | Part of wheelset - Merida Team SL45; 100x12mm; Center lock; With Merida Expert SL axle |
| hub rear | Part of wheelset - Merida Team SL45; 142x12mm; Center lock; With Merida Expert SL axle; including removable lever; 6/4mm allen key |
| rear brake | SRAM ED Rival eTAP AXS; hydraulic disc brake caliper with SRAM DB Center lock Paceline; 160mm rotor |
| rear derailleur | SRAM Rival eTAP AXS; SS |
| rims | Part of wheelset - Merida Team SL45; 19mm inner rim width; 45mm depth; carbon |
| saddle | Merida Expert SL; V-mount; including Merida minitool |
| seatpost | Merida Team SL; 27.2mm diameter; 15mm lay back; Carbon; S-Flex |
| shift levers | SRAM Rival eTAP AXS HRD |
| spokes | part of wheelset |
| stem | FSA SMR ACR; aluminium; -6 degree rise. Stem length: 90mm XXS/XS, 100mm S, 110mm M, 120mm L/XL |
| tyres | Front tyre: Continental Grand Prix 5000; 700 x 28c; Kevlar bead, folding Rear tyre: Continental Grand Prix 5000; 700 x 28c; Kevlar bead, folding |
| MPN | A62211A04645 |
| PNUM | 19426 |
| PRICE | £4250.00 |
| Available now |
Click here to view finance options.
Call 029 2052 9955 or email us and this bike could be yours today!
Size guide| RIDER HEIGHT | FRAME SIZE SUGGESTED | ||
|---|---|---|---|
| (ft - in) | (cm) | Size | (cm) |
| 4' 10" - 5' 0" | 148 - 152 | XXS | 47 - 48 |
| 5' 0" - 5' 3" | 152 - 160 | XS | 49 - 50 |
| 5' 3" - 5' 6" | 160 - 168 | S | 51 - 52 - 53 |
| 5' 6" - 5' 9" | 168 - 175 | M | 54 - 55 |
| 5' 9" - 6' 0" | 175 - 183 | L | 56 - 57 - 58 |
| 6' 0" - 6' 3" | 183 - 191 | XL | 58 - 59 - 60 |
| 6' 3" - 6' 6" | 191 - 198 | XXL | 61 - 62 - 63 |
| RIDER HEIGHT | FRAME SIZE SUGGESTED | ||
|---|---|---|---|
| (ft - in) | (cm) | Size | (cm) |
| 4' 10" - 5' 1" | 147 - 155 | XXS | 44 - 45 - 46 |
| 5' 1" - 5' 3" | 155 - 160 | XS | 47 - 48 - 49 |
| 5' 3" - 5' 5" | 160 - 165 | S | 50 - 51 - 52 |
| 5' 5" - 5' 8" | 165 - 172 | M | 53 - 54 - 55 |
| 5' 8" - 5' 10" | 172 - 180 | L | 56-57 |
