Frame size
XS
S
M
L
XL
Seat tube length (mm)
360
400
440
480
520
Chainstay length in millimeters
430
430
430
450
450
Reach in millimeters
371
393
411
426
443
Stand over height (mm)
680
710
730
765
780
Top tube length in millimeters
545
570
590
615
635
wheelbase (mm)
1063
1089
1110
1154
1175
Head tube angle
68
68
68
68
68
Head tube length in millimeters
105
115
125
125
135
Bottom bracket drop (mm)
45
45
45
60
60
Stack height (mm)
588
598
607
632
641
Seat tube angle
73.5
73.5
73.5
73.5
73.5
Pay in 3 instalments of £166.33* or in 30 days.
Available on all full price items.
We accept Cycle Scheme
Save up to £210
Pay with Cycle Scheme
Specification| Availability | In stock |
|---|---|
| BIKE year | 2026 |
| Category | Mountain Bike |
| Colour | Ink blue/dusty green - glossy |
| Condition | Brand new |
| Bike Geometry | Bottom bracket drop mm: |
| 45 mm | 60 mm |
| Chain stay length mm: | |
| 430 mm | 450 mm |
| Fork offset mm: | |
| 300 mm | Head tube angle: |
| 68 degrees | Head tube length mm: |
| 105 mm | 115 mm |
| 125 mm | 135 mm |
| Reach mm: | |
| 371 mm | 393 mm |
| 409 mm | 426 mm |
| 443 mm | Stack mm: |
| 588 mm | 598 mm |
| 622 mm | 632 mm |
| 641 mm | Stand over height mm: |
| 680 mm | 710 mm |
| 735 mm | 765 mm |
| 780 mm | Seat tube angle: |
| 73.5 degrees | |
| Seat tube length mm: | |
| 360 mm | 400 mm |
| 440 mm | 480 mm |
| 520 mm | Top tube length mm: |
| 545 mm | 570 mm |
| 595 mm | 615 mm |
| 635 mm | Wheelbase mm: |
| 1063 mm | 1089 mm |
| 1133 mm | 1154 mm |
| 1175 mm | Brake system |
| Brake Front Brand: | |
| Tektro | Brake Front Kind: |
| HD-M280, 2 pistons, 180 mm | |
| Brake Front Mount: | |
| Post Mount | Brake Front Type: |
| Hydraulic Disc brake | Brake Rear Brand: |
| Tektro | Brake Rear Kind: |
| HD-M280, 2 pistons, 180 mm | |
| Brake Rear Mount: | |
| Post Mount | Brake Rear Type: |
| Hydraulic Disc brake | Brake Lever Brand: |
| Tektro | Brake Lever Kind: |
| HD-M280-BL | Brake Rotor Brand: |
| Tektro | Brake Rotor Kind: |
| TR180-35 180 mm, Centerlock | |
| Drivetrain | Bottom Bracket Brand: |
| Thun | Bottom Bracket Kind: |
| PASO-ML 68-73 | Bottom Bracket Type: |
| BSA | Cassette Brand: |
| Shimano | Cassette Kind: |
| Tourney CS-HG200-7, HG | |
| Cassette Teeth: | |
| 12-32T | Chain Brand: |
| KMC | Chain Kind: |
| Z51 8s | Crank Arm length: |
| 170 | Crankset Brand: |
| Shimano | Crankset Kind: |
| Tourney FC-TY301 | Crankset Teeth: |
| 42-34-24T | Crankset Type: |
| triple | Derailleur Front Brand: |
| Shimano | Derailleur Front Kind: |
| Tourney FD-TY600-L6 3x6/7s, Top Swing | |
| Derailleur Hanger Brand: | |
| Ghost | Derailleur Hanger Kind: |
| GRH-21bl black + Screws FRHG0004 | Derailleur Rear Brand: |
| Shimano | Derailleur Rear Kind: |
| Tourney RD-TY300-SGS 6/7s, Double Servo | |
| Gear Brand: | |
| Shimano | Gear Type: |
| Derailleur | Pedal Brand: |
| XLC | Pedal Inclusive: |
| Yes | Pedal Kind: |
| Flat Pedal PD-M29 w/ Reflector + integrated Pins | |
| Shifter Left Brand: | |
| Shimano | Shifter Left Kind: |
| SL-M315-L 3x7s, Rapidfire+ | |
| Shifter Left Type: | |
| Triggershift | Shifter Right Brand: |
| Shimano | Shifter Right Kind: |
| SL-M315-7R, Rapidfire+ | |
| Shifter Right Type: | |
| Triggershift | Frame and more |
| Framesize: | |
| 36 cm | 40 cm |
| 44 cm | 48 cm |
| 52 cm | Framesize Convection: |
| XS | S |
| M | L |
| XL | Max loadable weight (KG): |
| 120 kg | Front Fork Brand: |
| Suntour | Front Fork Kind: |
| SF18-XCE28 DS 9mm-Dropout, 1-1/8" 100 mm | |
| Front Fork Type: | |
| Suspension | Frame Kind: |
| HIGH | Type kickstand mount: |
| KSA40 | Suspension Type: |
| Hardtail | Travel Front: |
| 100 mm | Handlebar and Saddle |
| Handgrip Brand: | |
| XLC | Grip Kind: |
| GR-S60 Sport Grip | Handlebar Brand: |
| XLC | Handlebar Diameter: |
| 31.8 mm | |
| Handlebar Kind: | |
| HB-C32, Dia. 31.8 mm, Rise: 25 mm, backsweep 15° | |
| Handlebar Material: | |
| Aluminium | Handlebar Rise: |
| 25 | Handlebar Type: |
| Riser Bar | Handlebar Width: |
| 740 mm | Headset Brand: |
| Glory Wheel | Headset Kind: |
| Strummer Headset, 1SI110 ZS44/ZS44 | |
| Headset Type: | |
| Semi-integrated | Saddle Brand: |
| XLC | Saddle Kind: |
| SA-S10 143 mm Sport | Seatpost Brand: |
| XLC | Seatpost Kind: |
| SP-R30, Dia. 31.6 mm, L: 350 mm | |
| SP-R30, Dia. 31.6 mm, L: 400 mm | |
| SP-R30, Dia. 31.6 mm, L: 450 mm | |
| Seatpost Length: | |
| 350 mm | 400 mm |
| 450 mm | Seatpost Material: |
| Aluminium | Seatpost Type: |
| Non Suspension | Stem Brand: |
| XLC | Stem Kind: |
| ST-M34, Dia. 31.8 mm, L: 50 mm, +/-7°, A-Head | |
| Stem Length: | |
| 50 mm | Wheels and wheel components |
| Hub Front Brand: | |
| XLC | Hub Front Kind: |
| HF-T20, QR 100 mm, 32H, Centerlock | |
| Hub Rear Brand: | |
| XLC | Hub Rear Kind: |
| HR-T10 QR 135 mm, 32H, Centerlock, HG | |
| Rim Brand: | |
| XLC | Rim Kind: |
| WR-M17 Disc 25/584 32H 6,5 mm Valve | |
| WR-M19 Disc 25/622 32H 6,5 mm Valve | |
| Rim Rear Brand: | |
| XLC | Rim Rear Kind: |
| WR-M17 Disc 25/584 32H 6,5 mm Valve | |
| WR-M19 Disc 25/622 32H 6,5 mm Valve | |
| Spoke Brand: | |
| DT Swiss | Spoke Kind: |
| FACTORY 2.0 | |
| Tyre Brand: | |
| XLC | Tyre Kind: |
| VT-M20 Summit | Tyre Rear Brand: |
| XLC | Tyre Rear Kind: |
| VT-M20 Summit | Tyre Size Etrto: |
| 57-584 | 57-622 |
| Wheel Size Front: | |
| 29 | 27.5 |
| Wheel Size Rear: | |
| 29 | 27.5 |
| MPN | 48KA0014 |
| PNUM | 21541 |
| PRICE | £499.00 |
| Available now | |
Click here to view finance options.
Call 029 2052 9955 or email us and this bike could be yours today!
Size guide
Mountain bike sizing for this model, with the available sizes shown alongside the guide.
Start with rider height, then adjust for reach, standover and riding style.
| Rider height | Frame size suggested | ||
|---|---|---|---|
| (ft - in) | (cm) | Size | (in) |
| 4' 10" - 5' 2" | 148 - 158 | XS | 13 - 14 |
| 5' 2" - 5' 6" | 158 - 168 | S | 15 - 16 |
| 5' 6" - 5' 10" | 168 - 178 | M | 17 - 18 |
| 5' 10" - 6' 1" | 178 - 185 | L | 19 - 20 |
| 6' 1" - 6' 4" | 185 - 193 | XL | 21 - 22 |
| 6' 4" - 6' 6" | 193 - 198 | XXL | 23 - 24 |
